TP-Link N300Mbps Wireless N Ceiling Mount Access Point – TL-EAP110

TP-Link N300Mbps Wireless N Ceiling Mount Access Point – TL-EAP110

Professional Ceiling-Mounted Wi-Fi Solution

The TP-Link TL-EAP110 is a high-performance N300 Wireless Access Point designed for ceiling mount installation in business environments. It offers reliable Wi-Fi coverage and is ideal for offices, hotels, schools, and other commercial spaces requiring seamless wireless connectivity.

Key Features

• 300Mbps wireless speed on 2.4GHz band
• Sleek ceiling mount design for discreet installation
• Power over Ethernet (PoE) support for flexible deployment
• Multiple operation modes: Access Point, Client, Multi-SSID, and Repeater

Easy Management and Setup

1. Centralized management with free EAP Controller Software
2. Intuitive web interface for standalone configuration
3. Easy mounting design for quick installation

Robust Performance

• MIMO technology for increased wireless range and stability
• Up to 100 concurrent wireless clients
• Band Steering for optimal client connection

Advanced Security Features

• Multiple SSIDs and VLAN tagging for network segmentation
• WPA/WPA2-Enterprise, 802.1X with RADIUS secure authentication
• Rogue AP detection for enhanced network protection

TP-Link N300Mbps Wireless N Ceiling Mount Access Point – TL-EAP110 Technical Specifications

Wireless Standards

IEEE 802.11n, IEEE 802.11g, IEEE 802.11b

Frequency

2.4-2.4835GHz

Wireless Speed

Up to 300Mbps

Transmit Power

<20dBm or <100mW

Antenna Type

2*3dBi Internal Omni-directional Antennas

Interfaces

• 1 10/100Mbps Ethernet Port (RJ45)
• 1 Kensington Lock

Power Supply

• 802.3af Power over Ethernet
• 12VDC Power Adapter (optional)

Dimensions (Dia. x H)

[Specify dimensions, e.g., 180 x 35 mm]

Max Power Consumption

6W

Operating Temperature

0℃40℃ (32℉104℉)

Operating Humidity

10% ~ 90%, non-condensing

Certifications

[List relevant certifications, e.g., CE, FCC, RoHS]

SSID

Up to 8 SSIDs

Wireless Functions

• Enable/Disable Wireless Radio
• Automatic Channel Assignment
• Transmit Power Control
• QoS (WMM)

Management

• Web-based Configuration (HTTP/HTTPS)
• CLI (Telnet)
• SNMP v1/v2c/v3
• Centralized Management via EAP Controller Software

Package Contents

• TL-EAP110 Wireless Access Point
• Mounting bracket
• Installation guide
• Mounting kit

The TP-Link TL-EAP110 N300Mbps Wireless N Ceiling Mount Access Point provides a professional-grade Wi-Fi solution for businesses, offering reliable performance, easy management, and flexible deployment options.
